Technical Specification for GNE make Tractor Trailer Gully Suction Machine
Advantage
| Tractor | Minimum 50hp Tractor |
| General | Trailer towed suction unit is able to create the vacuum as well as the pressure inside the tank body for siphoning of mud, slurry etc. from the sewage system. The unit is provided with sludge stirring arrangement by which pressurized air is formed into the manhole to silt the material form solid/ semi-solid to liquid/semi-liquid form and then sucking into the tank |
| Tank Capacity | 4000 liters |
| Material | 5mm thick M.S sheet [material conforming to IS :2062] |
| Shape | Cylindrical shell with knuckle radius dished end. |
| Construction | The Tank is fitted with anti-surge baffles to give dynamic stability to the vehicle. The tank is fitted with thick wall transparent acrylic tubing for sludge level indicator. The tank is interior is coated with epoxy paint for corrosion resistance. The tank is incorporated with cleanout valve. The tank is mounted is such a way that at any point of time load will be disturbed uniformly on the chassis. |
| Tire | 7-50*16 |
| Power By Auxiliary Engine | Power By Kirloskar Diesel Engine 6 hp. |
| Vacuum pump Make/type | Indian make rotary vane pump |
| Free air flow mix | 195 CU.M/HR |
| Max vacuum | 90% |
| Max pressure | 1.5bar |
| Set pressure | 0.5 bar |
| Salient feature | natural or forced convection air cooling in built lubricating pump inbuilt check value inbuilt change over valve asbestos free spark proof vanes
positive displacement of rotary vanes |
| Tank suction hose Type | Heavy –duty spiral bound neoprene kana flex suction hose. |
| Size | 75 mm diameter |
| Length | 15 meters |
| Tank suction valve Type/size | 80mm ball valve |
| Discharge valve Type / size | 100mm ball valve /butterfly valve |
| Auto shut off valve | Rubber ball float is provided inside the tank body to prevent the water entering into the vacuum pump due to overflowing of the tank |
| Secondary safety filter | Rubber ball float type secondary safety filter for pump safety which preventing water entering into the pump. |
| Strainer | Strainer is provider in pump suction line for safety |
| Pressure relief valve | INDIAN make a Heavy duty spring type adjustable pressure relief valve to safeguard the tank from excess pressure creating inside the tank |
| Extension pipe | Metal pipes of different length are provided with quick release coupling. These pipes are attached to reach the required depth of manhole /septic tank |
| Quick coupler | Imported Italian make quick coupler of sufficient diameter to connect the hose metal pipes. |
| Compound gauge | 100mm dial, pressure ranger: 0-2 kg/cm2, vacuum :0-760mm of Hg |
| Level gauge | Unbreakable sludge/water level gauge fitted throughout the height of the tank. |
| Rear door | Manual openable with hand operated wheel
Airtight heavy duty rubber gasket |
| Tank mounting | Tank is mounted in slope so that the sludge can be discharged by gravity or by pressurized discharge. |
| Paint | Epoxy paint inside the tank body. Two coat of zinc-based red oxide.
Two coat of synthetic enamel |
